Description

Includes

(1) EFD-K1612 Kick Drum

(1) EFD-S1250 Snare Drum

(1) EFD-T1070 Tom

(1) EFD-T1212 Floor Tom

(1) EFD-H14 Hi-hat

(2) EFD-C16 Crash Cymbal

(1) EFD-C18 Ride Cymbal

(1) EFD-C08 Splash Cymbal

(1) EFD-5X Module

(1) Tom Holder

(1) Splash Cymbal Arm

(1) Sound Module Arm

Optional Snare Stand & Cymbal Stand

** Does not include Hi-Hat Stand, Throne, and Bass Drum Pedal.

Specifications

Kick	EFD-K1612	Size: 16 x 12" Finish: White sparkle Zone: Head Sensor: Multi Head: Double-layered mesh with beater patch Connector: Head (TRS Phones) Features:Bass drum riser, Wood hoop
Snare	EFD-S1250	Size: 12 x 5" Finish: White sparkle Zone: Head / Rim / Side-Rim Sensor: Multi Head: Double-layered mesh Connector: Head/Rim, Side-Rim (2x TRS Phones) Features: Birch shell, Colored hoop rubber, Side-Rim
Tom	EFD-T1070	Size: 10 x 7" Finish: White sparkle Zone: Head / Rim Sensor: Multi Head: Double-layered mesh Connector: Head/Rim (TRS Phones) Features: Birch shell, Colored hoop rubber
Floor Tom	EFD-T1212	Size: 12 x 12" Finish: White sparkle Zone: Head / Rim Sensor: Multi Head: Double-layered mesh Connector: Head/Rim (TRS Phones) Features: Birch shell, Colored hoop rubber
Hi-Hat	EFD-H14	Size: 14" (Top/Bottom) Color: Warm gray Zone: Bow / Edge / Cup Sensor: Multi (360° flat sensing + choke) / Optical Connector: 6-pin Features: Multi-optical sensor, Tru-motion™ hi-hat, Weight simulation, Fine engraved surface General hi-hat stands compatible with φ12.7 mm (1/2") hole cymbal can be used. EFNOTE 5 sound module does not support hi-hat cup zone.
Crash	EFD-C16	Size: 16" Color: Warm gray Zone: Bow / Edge / Cup Sensor: Multi (360° flat sensing + choke) Connector: Bow/Edge, Cup (2x TRS Phones) Features: Weight simulation, Fine engraved surface
Ride	EFD-C18	Size: 18" Color: Warm gray Zone: Bow / Edge / Cup Sensor: Multi (360° flat sensing + choke) Connector: Bow/Edge, Cup (2x TRS Phones) Features: Weight simulation, Fine engraved surface
Splash	EFD-C08	Size: 8" Color: Warm gray Zone: Bow / Edge Sensor: Multi (360° flat sensing + choke) Connector: Bow/Edge (TRS Phones) Features: Weight simulation, Fine engraved surface

Sound Module: EFD-5

Trigger Interface	3-Zone: Snare, Crash 1/2*, Ride 2-Zone: Tom 1/2/3/4, HH, Crash 3 1-Zone: Kick Crash 1/2 support 3-zone with using Tom 4/Crash 3 cables. EFNOTE 5 uses the Crash 3 cable for the splash cymbal.
Audio / MIDI Interface	Line (1/2) Output: 2x TS Phone (+4dBu, Unbalanced) Phones (3/4) Output: Stereo Mini-Phone (320 mW + 320 mW @32Ω) Audio Input: Stereo Mini-Phone (+2dBu Max) USB Audio: 8-ch Output / 2-ch Input (Mac/Windows ASIO) USB MIDI In/Out Bluetooth Audio Input Bluetooth MIDI In/Out MIDI Out: 5-pin DIN
Drum Kits / Instruments	Preset Drum Kits: 17 (Editable) User Drum Kits: 83 Instruments: Acoustic Drums/Cymbals (Stereo), Percussion (Stereo), Attack Elements User Inst Library: 128 (Can be stored customized instruments)
Edit Parameters	Level, Pan, Tuning, Muffling (for each pad) 2-Band EQ (for each pad) Ambience Effect (8 Types) Pad Layer
Dimensions	172 (W) x 106 (D) x 47 (H) mm 700 g Excluding protrusions
Power	DC 12 V, 500 mA (Nominal) / 800 mA (Max)
