Roland SPD-30 Octapad Digital Percussion Pad

The OCTAPAD Legend Continues

Features

For decades, Roland has been a leader in electronic percussion technology. The original OCTAPAD was a revolutionary percussion instrument that was adopted by musicians worldwide and set the standard for future percussion pads. With the OCTAPAD SPD-30, an exciting new chapter in Octapad history begins. Combining cutting-edge drum and percussion sounds with the latest triggering technology, a Phrase Loop function, USB MIDI, and much more, the OCTAPAD SPD-30 is a rugged instrument that’s versatile for any musical application.

Specs

Pads

Built-in Pads: 8
* Four external trigger inputs are provided, allowing you to connect Pads.

Instruments

670

Kits

50

Kit Chain

8 chains (20 steps per chain)

Instrument Parameters

Tuning, Muffling, Soft Attack, Tone Color, Pitch Sweep, Volume, Pan, Reverse

Effect Types

Ambience (7 Types), Equalizer, Limiter, Multi Effect (30 Types)

Phrase Loop

Phrases: 50, Parts: 3, Tempo: 40 to 260, Resolution: 480 ticks per quarter note, Recording Method: Real-time, Maximum Note Storage: approx. 10,000 Notes

Display

160 x 160 dots Graphic Type LCD (Backlit LCD)
Pad Status Illumination x 8 (LED)

Connectors

PHONES Jack (Stereo 1/4 inch phone type), OUTPUT Jacks (L (MONO), R) (1/4 inch phone type), MIX IN Jack (Stereo 1/4 inch phone type), EXTERNAL TRIGGER INPUT Jacks x 4, HH CTRL Jack, FOOT SW Jack (1/4 inch TRS phone type), MIDI Connectors (IN, OUT), USB MEMORY Connector (for USB Memory), USB MIDI Connector (for USB MIDI)

Output Impedance

1.0 k ohms

Power Supply

AC Adaptor (DC 9 V)

Current Draw

600 mA

Accessories

Owner's Manual, AC Adaptor (PSB-1U), Screws (M5 x 12 mm) x 4

Options

Pads (PD series, PDX series), Cymbals (CY series), Kick Triggers (KD series), Hi-Hats (VH-11), Hi-Hat Control Pedal (FD series), Pad Stand (PDS-10), All-Purpose Clamp (APC-33), Acoustic Drum Trigger (RT-10K, RT-10S, RT-10T), Pedal Switch (DP-2), Foot Switch (FS-5U, FS-6), Personal Drum Monitor: PM-10, PM-30, V-Drums Accessory Package: DAP-3, V-Drums Mat: TDM-10,
USB memory
* Use USB memory sold by Roland. We cannot guarantee operation if other
products are used.
